VENSET TS700A electrical built-in TV lift
With the VENSET TS700A electrical TV installation lift, you can hide your monitor or TV in or behind furniture and push it out at the push of a button whenever you need it.
VENSET electric built-in TV lift TS700A
Venset offers electric TV lifts for all purposes. The TS700A is an electrical installation solution for your flatscreen. You can mount the TV-Lift directly on the wall and then hide, sink into a cabinet or the kitchen sink or let it be lowered from the ceiling. Do not limit your imagination!
The VENSET TV Lift can be flexibly integrated into the design of your living room, home office or bedroom. Hide the TV or monitor when you do not need it and bring it back to the front by pressing a button on the remote control.
Key features VENSET electrical built-in TV lift TS700A:
- Electrical TV lift for built- in solutions
- Load capacity: 65 kg
- Load capacity mounted upside down: max. 29 kg
- Unit weight: 16 kg
- VESA mount standard: 100x100, 200x100, 200x200, 300x300, 400x100, 400x200, 400x300 and 400x400 mm
- Stroke: 700 mm
- Height of the lift retracted: 600 mm
- Height of the lift extended: 1300 mm
- Adjustable stroke: yes
- Easy manual adjustment of the retraction and extension stop
- Input power: 110-240 V AC, 50-60 Hz
- Operation manually via panel
- Operation by radio remote control
- Optional: Operation via infrared remote control
- Finish: black
Does your monitor or display fit?
We are happy to check if your monitor is suitable for this VENSET TS700A mount. Simply send us your model (manufacturer + model no.) At the end of the order process. We then check for you whether the monitor or the display fits the monitor holder and if not, we will contact you.
VESA standard - Read more about the VESA standards of monitor brackets!
| Product sheet: |  [pdf, 473 kb] |
|---|---|
| Technical drawing: | [pdf, 128 kb] |
| 3D CAD Modell: |  [stp, 1,1 MB] |
| Installation manual: | [pdf, 484 kb] |
| Capacity: | 65 kg |
| Tilt: | - |
| Height range (mm): | 700 mm |
| Screen size: | 32" - 60" |
| Special features: | Eingebaute automatische Umkehrfunktion |
| VESA Standard: | 200x200, 400x200, 300x300, 400x400mm (www.vesa-standard.de) |
| Accessories: | Venset IR Fernbedienung R119090 |
| Contains installation material: | + |
| Manufacturer/Importer: | VENSET A/S, Industrivej 23, 6900 Skjern, Denmark, info@venset.com |
| Warranty: | 2 years |
| Inch size: | 32 inch, 34 inch, 35 inch, 37 inch, 38 inch, 40 inch, 42 inch, 43 inch, 46 inch, 47 inch, 48 inch, 49 inch, 50 inch, 52 inch, 55 inch, 58 inch, 60 inch |
| Mobility: | electrical, height adjustable |
| Mounting type: | Lift |
| Multi-monitor mount: | 1 monitor |
| Theft-proof: | No |
| color: | Black |
| VESA (in mm): | VESA 200x200, VESA 300x200, VESA 300x300, VESA 400x200, VESA 400x300, VESA 400x400 |
If warning and safety instructions are to be observed for a product, these can be found in the respective installation instructions or in a separate PDF, depending on the manufacturer. Available documents for the product can be found in the available PDF files (see above).
Download area - catalogs, flyers, warranty conditions, ...
6 November 2024 08:35
Endlich eine ordentliche Hebebühne für's TV
Ein sicherer und zuverlässiger Lift, leise und schnell auszufahren; immer wieder ein Hingucker für Gäste, die in dem gebauten Schrank keinen Fernseher vermutet haben und dann beim Ausfahren sehr erstaunt sind. Für das bequeme Bedienen aus dem Bett oder vom Sofa wurde eine Fernbedienung hinzu bestellt; ein Kauf der sich gelohnt hat.
