Novus TSS support carriage monitor mount for slatwall (963+0119+013)
Slatwall monitor mount
The Novus TSS Slatwall monitor mount (963+0119+013) is a swivelling monitor bracket for mounting a display / monitor on an organisation wall or SlatWall. The monitor holder supports flat screens weighing up to 10 kg and has a quick-release for fast replacement or installation of a screen.
The screen holder is suitable for perfect organisation at the workplace. The monitor holder with support carriage has a VESA mount of 75x75 and 100x100 mm. The short monitor support arm has a maximum reach of up to 110 mm and has a swivel range of 60 mm to the left and right.
Key features Novus TSS display holder 963+0119+013
- Easy monitor attachment to Slatwall elements
- Mandatory addition is a SlatWall element
- VESA mount: 75x75 and 100x100 mm
- Support capacity: max. 10 kg
- Individual viewing angle adjustment due to a swivel range of 60°
- Individually adjustable lightness
- High mobility in confined spaces due to ball-and-socket joint
- Range: 110 mm
- Elegant aluminium finish with anodised surfaces
- Colour: silver / anthracite
- Warranty: 5 years
Does your screen or display fit the VESA mount?
We will be happy to check whether your monitor is suitable for this Novus TSS monitor mount for slatwall (963+0119+013). Simply tell us your model (manufacturer + model no.) in the comments field at the end of the ordering process. We will then check for you whether the monitor or display fits the monitor mount and if not, we will contact you.
VESA Standard - Learn more about the VESA standard for monitor mounts!
| Product sheet: |  [pdf] |
|---|---|
| Technical drawing: | [pdf] |
| Installation manual: | [pdf] |
| Capacity: | 10 kg |
| Swivelling range: | +/- 60° |
| Length of the swivel arm: | 110 mm |
| Screen size: | 19 - 27" |
| VESA Standard: | 75x75mm, 100x100mm MIS-D (www.vesa-standard.com) |
| Suitable for: | Novus Slatwall |
| Packaging dimensions (LxWxH in mm): | 200 x 180 x 130 |
| Scope of delivery: | 1x Slatwall support carriage incl. installation material |
| Contains installation material: | + |
| Manufacturer/Importer: | Novus Dahle GmbH, Breslauer Straße 34-38, 49808 Lingen (Ems), info@novus-dahle.com |
| Warranty: | 5 years |
| Inch size: | 15 inch, 17 inch, 18 inch, 19 inch, 20 inch, 21 inch, 22 inch, 23 inch, 24 inch, 25 inch, 26 inch, 27 inch |
| Mobility: | swivelling |
| Multi-monitor mount: | 1 monitor |
| Theft-proof: | No |
| color: | Silver/Anthracite |
| VESA (in mm): | VESA 75x75, VESA 100x100 |
If warning and safety instructions are to be observed for a product, these can be found in the respective installation instructions or in a separate PDF, depending on the manufacturer. Available documents for the product can be found in the available PDF files (see above).
