TecLines TKM004W keystone module HDMI 2.0 4K socket/socket, white
The TecLines TKM004W custom module HDMI 2.0 socket / socket keystone is a white keystone module for mounting in keystone frames. Transmission up to a resolution of 3840x2160 (UHD/4K) is possible.
HDMI keystone module
Keystone modules offer a flexible way to combine technical interfaces in mounting frames power strips. The TecLines custom modules are the central building blocks for video, audio and network connections. Thanks to the standardized design, installation is flexible and simple. The HDMI keystone module in white is equipped with a snap-in insert and is also suitable for installation in Keystone snap-in module plates or snap-in patch panels. Video transmission with a resolution of up to 4K / 60 Hz is possible with the TecLines TKM004W keystone module. The gold-plated plug contacts increase conductivity and protect against corrosion.
Perfect for the office & various other applications: The HDMI 2.0 4K module with 2x socket is very well suited to bring sockets with custom modules at office workstations, in conference rooms, entrance areas, exhibition halls, in hotels or at the private desk technically to a high level.
Key features TecLines TKM004W HDMI 2.0 4K keystone module
- Keystone mounting
- Socket / socket (through-hole) for tool-free connection on front and rear side
- Can be integrated into power strips / socket installation frames such as Bachmann Desk 2
- Front: Type A socket HDMI 2.0
- Rear: Type A socket HDMI 2.0
- Transmission: up to a resolution of 3840x2160 (UHD/4K) possible
- Case depth: 29 mm
- Outer dimensions: 29 x 16 x 15 mm
- Suitable cables can be ordered separately
- Resolution: max. 4K / 60Hz
- Housing material: plastic
- Color: White
| Product sheet: |  [pdf] |
|---|---|
| Packaging dimensions (LxWxH in mm): | 280 x 200 x 15 |
| Scope of delivery: | 1x HDMI 2.0 4K keystone module |
| Contains installation material: | + |
| Manufacturer/Importer: | BCS Business Creative Solutions GmbH / TecLines, Am Marienhof 8, 22880 Wedel, info@teclines.de |
| color: | White |
If warning and safety instructions are to be observed for a product, these can be found in the respective installation instructions or in a separate PDF, depending on the manufacturer. Available documents for the product can be found in the available PDF files (see above).
