SmartMetals Floor lift XL for touch screen max. 86 inch, 135 kg
The SmartMetals Floor lift XL for touch screen max. 86 inch allows easy mounting of a monitor lift. The hub is designed to be 600 mm tall and provides the right height adjustment for everyone.
SmartMetals Floor lift XL for touch screen max. 86 inch, 135 kg - 052.7200
With the SmartMetals floorstans with Lift XL for up to 86 inch touchscreens floor lifts can be moved quickly and simply. It enables the electric height adjustment of screens. The lifts are equipped with a screen mount that supports most VESA hole patterns up to 600 x 400 mm which makes them suitable for almost any display. The device can be positioned next to a wall, then it is attached to the wall bracket. The floor lift is delivered with a remote control to set the display to 600 mm height. Behind the screen mount there is room reserved for placing a minicomputer. For the use of a thin client PC, a VESA 100 x 75 mm hole pattern is prepared.
Multiple application capabilities. The Floor lift XL opens a wide range of possible applications. Whether as a digital presentation medium in classrooms, auditoriums and workshops or as Point of Information in merchants, train stations or tourist information. Due to the extensibility of the lift system, there are still other application scenarios possible. Customize the lift system to your needs with plenty of accessories.
Technical Details Floor lift XL for touch screen max. 86 inch
- Color: Black, Aluminum
- Net weight: 30.8 kg
- Dimensions (WxD): 680 mm x 175 mm
- Capacity: 135 kg
- Electrically height adjustable by 600 mm (max 20mm/s)
- Screen Orientation: Portrait or Landscape
- Floor Stands with Lift XL for Screens
- Cable Guide: 30 mm
- Min./Max. Length display unit: 1145 mm / 1745 mm
VESA Standard - Learn more about the VESA standard of monitor mounts !
Does your monitor or display fit?
We'll be happy to let you know if your monitor is suitable for this SmartMetals product. Simply submit us your model (manufacturer + model no.) after placing the order. We will then check to see if the monitor or display fits the monitor mount and if not, we will contact you. Of course, you can contact us with any other questions. Our team will be happy to answer all your questions about the products offered.
| Product sheet: |  [pdf] |
|---|---|
| Technical drawing: | [pdf] |
| Installation manual: | [pdf, 5,5 Mb] |
| Capacity: | 135 kg |
| Height range (mm): | 600 mm |
| Screen size: | 55 - 86 " |
| Material: | Metall |
| Special features: | Elektrisch Höhenverstellbar |
| VESA Standard: | 200x200, 300x200, 300x300, 400x200, 400x300, 400x400, 600x200, 600x400 mm (www.vesa-standard.de) |
| Packaging dimensions (LxWxH in mm): | 1060 x 220 x 800 |
| Contains installation material: | + |
| Manufacturer/Importer: | SmartMetals Mounting Solutions B.V., Hondsruglaan 93, 5628 DB Eindhoven, Niederlande, E-Mail: info@smartmetals.nl |
| Warranty: | 5 years |
| Inch size: | 55 inch, 58 inch, 60 inch, 63 inch, 65 inch, 70 inch, 71 inch, 75 inch, 77 inch, 79 inch, 80 inch, 82 inch, 83 Zoll, 84 inch, 85 inch, 86 inch |
| Mobility: | electrical, height adjustable |
| Mounting type: | Floor stand |
| Multi-monitor mount: | 1 monitor |
| Theft-proof: | No |
| color: | Silver/Black |
| VESA (in mm): | VESA 200x200, VESA 300x200, VESA 300x300, VESA 400x200, VESA 400x300, VESA 400x400, VESA 600x200, VESA 600x400 |
If warning and safety instructions are to be observed for a product, these can be found in the respective installation instructions or in a separate PDF, depending on the manufacturer. Available documents for the product can be found in the available PDF files (see above).
