peerless SF680-HUB SmartMount wall mount Microsoft Surface Hub 84"

Peerless-AV has introduced a new line of trolleys and wall mounts for the 55" and 84" versions of the Microsoft Surface Hub: use the mobile solution in corporate, hospitality and education environments, while the wall mounts are suited to more permanent installs.

peerless SF680-HUB SmartMount wall bracket Surface Hub 84"

The SmartMount® Universal Flat Wall Mount for the Microsoft Surface Hub provides a strong and stable foundation for the 84" Microsoft Surface Hub. The wall plate includes multiple mounting locations so you can center the display on 16", 20", 24", 32", 40" and 48" stud centers. The mount includes security hardware to help deter tampering and theft.

The open wall plate design ofers total wall access, increasing the electrical and cable management options. The surface display can now simply be installed by a single person with the Hook-and-Hang™ system. The Easy Glide™ adaptors hook onto the wall plate for an overall quick, simple, and secure installation.

Key fetaures Peerless fixed Surface wall mount SF680-HUB

• Universal Flat Wall Mount for the 84" Microsoft Surface Hub
• Finish: Black
• Scratch Resistant Fused Epoxy
• Capacity: 136,1 kg
• VESA-Standard: 200x200, 400x200, 400x400, 600x400, 600x600, 800x600, 1000x600 - max. 1200x600 mm
• Wall distance: 54 mm
• Universal mount its displays with mounting patterns up to 1256 x 608mm (49.45" x 23.94")
• Easy-Glide adaptors Hook onto the wall plate for quick, simple and secure installation
• Mounts to wood studs, concrete, cinder block or metal studs (metal stud accessory required)
• Design is UL® listed and tested to four times stated load capacity
• Includes all necessary wall and display attachment hardware
• Anti-theft security hardware included

Microsoft® Surface Hub 84" (not included in delivery):

• Operating system: Windows 10
• Screen Size: 84 Zoll (1171.5 x 2202.9 x 105.4 mm)
• Display: 4k Resolution (3840 x 2160)
• Aspect ratio: 16:9
• Touch: 100-point multi-touch
• Weight: approx. 127 kg
• CPU: 4te generation Intel®Core™ i7 with Nvidia Quadro K2200 graphics
• Memory: 128 GB SSD, 8 GB RAM
• 2x Surface Hub Pen included
• Network: Wi-Fi (802.11 a/b/g/n/ac), Ethernet 1Gbps, Bluetooth 4.0 low energy, NFC Reader, Miracast capable
• Cameras: Dual 1080p cameras front (100 degree horizontal field of view)
• Audio: 4-element array microphone, Dual stereo front speakers
• Connections: 1x USB 3.0, 4x USB 2.0, Ethernet 1Gbps, DisplayPort Out, 3.5mm Stereo Out, RS232 Serial (RJ11). DisplayPort In, HDMI In, VGA In, 3.5mm Stereo In, 2x USB 2.0 type B

Does your monitor or display fit?

We are happy to check whether your monitor is suitable for this peerless AV mount SF680-HUB. Simply send us your model (manufacturer + model no.) At the end of the ordering process. We then check for you whether the monitor or the display fits the monitor holder and if not, we will contact you.

VESA standard - Read more about the VESA standards of monitor brackets!
