Novus SKY BASIC 1 swivelling TV wall mount for caravans, motorhomes
The wall mount Novus SKY BASIC 1 for flatscreens is perfect for caravans and campers.
Swivel TV wall mount
For over 30 years equips Novus caravans, campers, motor homes, buses, cars sale, cars and boats with high-quality technical details. The swivel TV mount for flat panel displays counts of the highlights in the range.
Thanks to a large mounting plate, a very solid locking of the support arm and safe handling of the monitor adapter makes the stable swivel TV wall bracket television while camping fun and safe at the same time. Easy is it to the support arm pivot, so that the flat panel is always brought in seconds in ideal position. Convincing Result: freedom of movement - even in tight spaces.
A generous and goal-oriented usable monitor mount provides a free space and more mobility. The two-part articulated arm is equipped with a widely used flat-screen mount (VESA 75/100).
Key features Novus SKY BASIC 1 TV wall holder
- Wall mount for caravan and campers
- Distance to wall: 33,5 - 156,5 mm
- Length swivel arm: approx. 156 mm
- Suitable for attachment standard 75/100
- Adapter for easy monitor mounting at support element
- Mounting of flat screens up to 7 kg
- Lever length: approx. 250 mm
- Lever can be mounted up and down, 30mm pitch
- Ergonomic monitor settings by various joints
- Swivel: 180°
- Tilt: +/- 10°
- Perfect cable management by cable clips
- Finish: Black
Does your monitor or display suit?
We will gladly check if your monitor is suitable for this bracket. Simply send us at the end of the ordering process in the comment box your model (Manufacturer + model no.). We will then check for you whether the monitor or the display to monitor mount fits and if not, we will contact you.
If you are interested in more information about VESA-Standards for monitor brackets click here!
| Technical drawing: |  [pdf] |
|---|---|
| Installation manual: | [pdf] |
| Capacity: | 7 kg |
| Tilt: | +/- 10° |
| Swivelling range: | 180° |
| Screen size: | 14" - 24" |
| Depth of the bracket: | 33,5 mm |
| Old model no.: | 01608T20099SB |
| VESA Standard: | 75x75mm, 100x100mm MIS-D (www.vesa-standard.com) |
| Scope of delivery: | 1x SKY BASIC 1 TV holder + installation materials |
| Contains installation material: | + |
| Manufacturer/Importer: | Novus Dahle GmbH, Breslauer Straße 34-38, 49808 Lingen (Ems), info@novus-dahle.com |
| Warranty: | 2 years |
| Inch size: | 14 inch, 15 inch, 17 inch, 18 inch, 19 inch, 20 inch, 21 inch, 22 inch, 23 inch, 24 inch |
| Mobility: | swivelling, tilting |
| Mounting type: | wall mount |
| Multi-monitor mount: | 1 monitor |
| Theft-proof: | No |
| color: | Black |
| VESA (in mm): | VESA 75x75, VESA 100x100 |
If warning and safety instructions are to be observed for a product, these can be found in the respective installation instructions or in a separate PDF, depending on the manufacturer. Available documents for the product can be found in the available PDF files (see above).
