Novus Clu Plus C monitor desk mount up to 40 inch (991+3018+000), black
Monitor table mount
The monitor table mount with swivel arm from Novus (991+3018+000) is due to its load capacity of 15 kg especially suitable for large and heavy displays such as modern curved monitors with up to 40 inches. The monitor desk holder skilfully combines power, functionality and handling to promote an ergonomic posture at the workplace. By means of gas pressure spring, the screen can be aligned particularly smoothly to the ideal viewing angle. Additional flexibility is provided by the pivot function, which enables a quick switch between landscape and portrait mode. The installation on the desk is carried out by desk clamp, cable hole or drill screw fastening, as desired. Thanks to the practical Novus QuickRelease system, the height-adjustable monitor mount can be snapped onto the VESA mount in a few simple steps, or removed again if required. The integrated cable holders and covers ensure tidy cable management.
Spacer Screws Set
For mounting certain monitor / TV models with recessed VESA screw holes, it is necessary to bridge the distance of the recess with spacers. With the Novus spacer screws set (796+0905+000), the monitor mounts from the Novus CLU series can be mounted on almost all TVs.
Key features Novus Clu Plus C monitor desk bracket (991+3018+000)
- Screen sizes: 19 - 40 inch
- Load capacity: 15 kg
- Ideally suited for modern curved monitors
- Gas pressure spring for comfortable, ergonomic adjustment
- Easy and quick installation of the monitors by QuickRelease
- VESA mount: 75x75, 100x100 mm
- Swivel: 360 degrees with adjustable stop at 180°
- Height adjustable: 150 - 450 mm (center of VESA mount to table surface)
- Tilt: 70°
- Rotate: 360° (pivot)
- Flexible 3-in-1 mounting: desk clamp, cable hole mount and drill screw mount
- Suitable for table thickness: 10 - 50 mm
- Integrated cable guide
- Reach: 525 mm
- Included in delivery: Spacer screws set (796+0905+000)
- Color: Black
- Warranty: 5 years
- Previous models: Novus LiftTEC Arm I (930+1159+000), Novus LiftTEC Arm II (930+2159+000), Novus LiftTEC Arm III (930+3159+000)
Does your display fit the monitor mount?
We would be happy to check whether your monitor is suitable for this Novus Clu Plus C monitor desk mount (991+3018+000). Just tell us your model (manufacturer + model number) in the comment field at the end of the ordering process. We will then check for you whether the monitor or display fits the monitor mount and if not, we will contact you.
VESA standard - Learn more about the VESA standard of monitor mounts!
| Product sheet: |  [pdf] |
|---|---|
| Technical drawing: | [pdf] |
| Others: | [pdf] |
| Installation manual: | [pdf] |
| Minimum weight: | 6 kg |
| Capacity: | 15 kg |
| Tilt: | 70° |
| Height range (mm): | 150 - 450 |
| Swivelling range: | 360° |
| Length of the swivel arm: | 525 mm |
| Screen size: | 19 - 40" |
| Thickness of table (mm): | 10 - 50 |
| Material: | Aluminum, plastic |
| VESA Standard: | 75x75, 100x100 mm (www.vesa-standard.com) |
| Scope of delivery: | 1x Clu Plus C monitor mount with table attachments | 1x spacer screw set | installation material |
| Contains installation material: | + |
| Manufacturer/Importer: | Novus Dahle GmbH, Breslauer Straße 34-38, 49808 Lingen (Ems), info@novus-dahle.com |
| Warranty: | 5 years |
| Inch size: | 19 inch, 20 inch, 21 inch, 22 inch, 23 inch, 24 inch, 25 inch, 26 inch, 27 inch, 28 inch, 29 inch, 30 inch, 31 inch, 32 inch, 34 inch, 35 inch, 37 inch, 38 inch, 40 inch |
| Mobility: | height adjustable , rotatable, swivelling, tilting |
| Mounting type: | desk - cable hole fastening, desk - clamp, desk - drill screw fastening |
| Multi-monitor mount: | 1 monitor |
| Theft-proof: | No |
| color: | Black |
| VESA (in mm): | VESA 75x75, VESA 100x100 |
If warning and safety instructions are to be observed for a product, these can be found in the respective installation instructions or in a separate PDF, depending on the manufacturer. Available documents for the product can be found in the available PDF files (see above).
