MonLines MLE675S myTVLift wall mount 675 with housing, silver

MonLines MLE675S myTVLift wall mount 675 with housing in silver

Frugal, stable TV lift wall mount. With a high capacity and very stable lifting column, this MonLines TV lift MLE675S in silver with housing is considered classic among the electrical mounts. It can be operated manually or by remote control and the lift thrilles by its low noise level. Any modifications and special colors are possible with MonLines myTVLift.

Key features MonLines MLE675S myTVLift wall mount 675 with housing

• Extension height of the lift is 670mm
• Incl. housing
• Standard: 570mm
• Mounting: Wall mount
• Capacity: 40 kg
• VESA mount: 75x75, 100x100, 200x100, 200x200, 300x200, 300x300, 400x200, 400x300, 400x400mm
• Infinitely variable height adjustment of the monitor holder of 675 mm
• Speed ​​up to 43 mm / s
• Double-acting brake for increased self-locking ability
• Ambient temperatures +5 ° C to +40 ° C
• High-quality powder coating
• Silver color RAL9006
• Manual operation of panel
• Operation by infrared remote control
• Optionally available: MonLines MLS029 control cable for contact switch

The control box ensures that the application has a low and pleasant noise level and a constant speed in normal work areas.

Control box:

• Supports up to 2 actuators / columns
• Line voltage: 120 VAC, 220-240 VAC, 50-60 Hz
• Compact, powerful toroidal transformer
• Power consumption in standby mode is due to the toroidal transformer only 1.6 watts
• Finish: black
• Interchangeable standard network cable
• Overload protection (EOP), current limiting
• Soft-Start/Stopp-Function
• Strain relief for power cord
• Automatically detects the number of connected drives
• Automatic detection of the connected drive type
• Duty cycle: Max. 10% ~ 6 minutes per hour and 2 minutes of continuous operation at full load
• Tested according to EN 60335-1, UL 962 and the Australian Standard AS/NZS3197

The panel and the remote control are the basis for a wireless control system based on infrared transmission. The panel serves as a receiver while the remote control sends signals to the system via the panel. The system is particularly useful in applications such as furniture for flat panel displays.
panel.

Panel:

• Operating device for a single channel or parallel systems
• Finish: black
• 1.580 mm straight, black cable with modular jack connector

Remote control:

• Finish: grey
• Cordless with 3 AAA batteries
• Hand control to control 1 or 2 References
• Easy to use for right-and left-handers
• Distance range is approximately 6m

Does your TV fit with the wall mount?

We will gladly check if your monitor (display, TV, LED, LCD, plasma, TFT, screen) is suitable for this MonLines MLE675S holder. Simply send us your model (manufacturer + model no.) at the end of the ordering process in the comment field. We will then check for you if the TV fits and if not, we will contact you.

VESA standard - Read more about the VESA standards of monitor brackets!
