Bachmann Loop Square cable outlet 120x240mm, silver (930.320)

Installation frame for cable outlet

Bachmann LOOP SQUARE installation frame (930.320) creates more flexibility on the desktop with generating free and effortless access to sockets or USB / HDMI connections under the working desk. When closed, the furniture surface and the LOOP SQUARE cable outlet forms a flat surface / level.

Cable routing through integrated brush insert

The Bachmann cable outlet with a black brush insert has an elegant, silver-anodized design and can be quickly and easily inserted into the table cut-out. No accessories are required. The cable outlet provides access to the multiple socket strip, which is located in the existing, commercially available cable tray under the tabletop. Cables can be routed through the opening in an uncomplicated manner. This also happens with the black brush insert when it is closed. The cables are not clamped. The cable bushing can be combined with BACHMANN STEP and UNIVERSAL, but also with any other commercially available socket strips. You only have to pay attention to the dimensions of the multiple socket list and the cable outlet. The multiple plug should not be larger than the cable outlet in the table. The perfect solution for cable management in offices, kitchens, conference and meeting rooms.

Key features Bachmann LOOP Square desktop cable bushing

• Finish: silver grey
• Material: aluminium
• Dimensions (WxD): 240 x 120 mm
• Installation depth: 25 mm
• Table cut-out dimensions: 113 x 213 mm
• Easy access to an up to 4-way power strip
• Closes when cables are plugged in
• Brush strip in black
• Straight hinged lid with black brush seal
• Scope of delivery: 1 x cable entry, 2 x screws and 1 x Allen key

Possible combinations for Bachmann LOOP SQUARE installation frames (not included in delivery)

• Bachmann STEP power socket strips
• Bachmann UNIVERSAL power socket strips
• Bachmann CONI COVER cable tray
